The Structural Engineer, Volume 37, Issue 4, 1959
THE paper gives a brief outline of the history, development, design considerations and construction of the Hydrodynamic Laboratory designed and built by the Ministry of Works for the National Physical Laboratory. Broadly, the new laboratory incorporates a main waterway with its carriage rails, wavemakers, beaches, trimming docks and assembly area and, also, separate manoeuvring and storage tanks, including the special buildings housing them. Associated with the tanks are the wax model shop, fitting shop, machine shop, woodworking shop, boiler house, offices and canteen. A. E. Hewitt
Not the least difficulty encountered in the design and construction of the Forth Bridge was the number of joints, as will be seen all too clearly in Fig. 1. Fifty years were to elapse before welding was used to connect small diameter tubes and it became possible to construct efficient and economical tubular structures. Such structures are designed to take advantage of the favourable characteristics of tubes in torsion, compression and tension, but the members are proportioned in accordance with the normal laws of statics, as in any other structure, The method of jointing, however, is peculiar to this form of construction. While the whole concept of tubular structures is based upon welding, bolts being used only for site connexions, it must not be imagined that the joints evolved without careful research and experiment. Finality has not been reached, either in the scope of tubular structures or in the design of joints, but it is hoped that these notes will enable structural engineers already familiar with conventional steelwork to design the joints in all but the most unusual tubular Structures. G. Bernard Godfrey
