The Structural Engineer, Volume 75, Issue 13, 1997
This is the first in a series of occasional columns on areas of law which are relevant to the profession. The columns will be written by personnel at Cameron McKenna, the Institution’s solicitors, who have extensive experience advising on building and civil engineering projects both in the UK and overseas. A. Rawstron
Mr J.E.M. Jubb (M) Traditionally, the plate girder is made with a flat web which is easy to cut accurately and handle. Fast, modern technology has simplified this process, allowing excellent fit-up between web and flange. The aim is to achieve lmm maximum lack of fit, or an increase in fillet weld size is necessary to compensate the gap.
This paper presents a strut-and-tie approach for the analysis of deep beams subjected to (i) top loading, (ii) bottom loading, and (iii) combined top-and-bottom loading. The model consists of three groups, i.e. concrete struts, nodal zones and steel ties from the reinforcement. Incorporated with appropriate criteria for each group, the model gives very good shear strength predictions of deep beams, in comparison with the values from the ACI Building Code, 318-95, the 1984 Canadian Code, and the UK CIRIA Guide 2. K.H. Tan, L.W. Weng and S. Teng
