Inchinnan Opening Bridge

The Structural Engineer
Inchinnan Opening Bridge
Date published

1st May 1923

First published

1st May 1923

Price

Standard: £9 + VAT
Members/Subscribers: Free

Buy Now

The new opening bridge over the River Cart at Inchinnan, near Renfrew, carries the principal road from Glasgow to Greenock and other west-coast ports, and is the only bridge over the Cart between Paisley and the Clyde, a distance of 3 miles. It provides an improved and widened navigation channel between Paisley and the River Clyde. The earliest attempt to improve the Cart navigation was made in 1753. The Cart Navigation Trust was formed in 1834, when the present swing bridge was erected over an artificial channel. The financial embarrassments of the Trust led to the undertaking becoming derelict in 1915. In 1920 power was granted to the Burgh of Paisley to improve the navigation-channel at Inchinnan and to replace the old swing bridge by a modern opening bridge. The widened channel has a clear width of 90 ft. and a depth of 21 ft. at high water length of about 250 ft. William Bertram Hall

Additional information

Format:
PDF
Publisher:
The Institution of Structural Engineers

Tags

Volume 1 (1923) Issue 5
