Author: Sparks, P R;Menzies, JB
N/A
Standard: £10 + VATMembers/Subscribers: Free
Members/Subscribers, log in to access
Sparks, P R;Menzies, JB
The Structural Engineer, Volume 51, Issue 11, 1973
Beams of varying depth are widely used in civil engineering structures, and are particularly suitable for large span prestressed concrete bridges. It is well known that the distribution of shear stress and hence principal tensile stress may be considerably affected by the variation in depth. A review is made of the various elastic analytical methods available, and their assumptions are discussed. The accuracy of each analysis is assessed on a plane wedge under separate application of normal force, shear, and bending moment, for a range of slopes and curvatures. The effect of curvature is shown to be unimportant for the values associated with bridges. The approximate forms of the solutions reached by Boussinesq and Wysiatycki are shown to be identical. These expressions are simple and give good agreement with the exact solution. Photo-elastic and finite element models are used to examine the accuracy of the various analytical methods applied to box-sections. Gwynnes Davies, Richard S. Lamb and Cyril Snell
The history of the Fort Regent from its origins to the present day are first described followed by the requirements of the States of Jersey and the evolution of the design now under construction. The engineering problems encountered and the derivation of design loadings together with the solutions to these problems and the design logic employed are discussed. The various structural elements that form the complete roof structure, such as the curved roof beams, fascia girders, portal frames, and the north and south ends and the dome, are fully described together with the design procedure for the structural elements and the methods of shop and site fabrication. W.H. davies, B.A. Gray and F.E.S. West
Mr. K. Kretsis (F) : I would like to ask a question with regard to tube combination by internal sub-division. The horizontal beam members of the external tube sides have a considerable stiffness, how is a comparable stiffness achieved in the horizontal beam members of the internal sub-divisions of the tubes so that they may have a substantial effect on the shear lag within the external cross-planes of the tubes?
