Alternative Design Methods for Parallel-Chord Space Trusses

The Structural Engineer
Alternative Design Methods for Parallel-Chord Space Trusses
Date published

N/A

First published

N/A

Author

Schmidt, L C

Price

Standard: £9 + VAT
Members/Subscribers: Free

Buy Now

A proposed plastic design method, depending on tension chord yield, for two-layer parallel-chord space trusses is discussed. The method is compared with the conventional elastic method and the strip method originally used in reinforced concrete slab design. The disadvantages of these last methods are shown in a comparison of complete analyses of three designs. The essential point made is that when tension chords begin to yield a set of membrane forces is developed: these forces are compressive in the region of the yielding tension members and increase in magnitude as the yielded tension zone increases. The proposed design method allows for this change of force distribution so that no compression member instability occurs, thereby furnishing a favourable load-deflexion characteristic for the structure. Reference is made to experimental results of tension member yield in planar trusses in order to justify the use of yielding tension members; it is noted that further work is necessary. L.C. Schmidt

Additional information

Format:
PDF
Publisher:
The Institution of Structural Engineers

Tags

Issue 8
